Standards and operating conditions

Mode

p500Controller

Conformity

Low-VoltageDirectiveCE 2014/30/EU

EAC

TPTC020/2011(TRCU020/2011)

Approval

ProcessControlEquipment(File-No.E236341) UL508C CSA22.2No.142UL/CSA

Degreeofprotection

EN60529 IP65(front) IP20(back) NEMA250 Type1

Climatic conditions Storage(EN60721-3-1) 1K3(Temperature:-5°C...+45°C) Transport(EN60721-3-2) 2K3(temperature:-25°C...+70°C) Operation(EN60721-3-3) 3K3(temperature:0°C...+55°C)

Degreeofpollution 2EN61131-2

Sitealtitude 3000[m]H maxAmsl

Vibrationresistance 1g Vibration(EN61131-2) 15g Mechanicalshock(EN61131-2) 5Hz≤f≤13.2Hz:±1mmamplitudeOperation(GermanischerLloyd)

Noiseemission Industrialpremises

EN61000-6-4 Noiseimmunity ESD:Severity3EN61000-4-2 150kHz...80MHz,10V/m80%AM(1kHz)EN61000-4-6 80kHz...1000MHz,10V/m80%AM(1kHz)EN61000-4-3 1.4GHz...2.0GHz,3V/m,80%AM(1kHz) 2.0GHz...2.7GHz,1V/m,80%AM(1kHz) Burst:Severity 3EN61000-4-4
